The fresh milk transporter produced by Chengli Special Vehicle Co., Ltd. is made of stainless steel 304 material for the inner and outer tanks. It can be made into 2-4 compartments. The outside of the tank needs to be insulated to prevent the deterioration of fresh milk, and the interior of the tank needs to be smooth and clean. , No acute angle, generally need to add a cip (cleaning device) tank in each milk tank with a washer; the middle layer is insulated with 50-80mm polyurethane foam material, and the temperature change does not exceed 1 in 24 hours when the temperature difference is 30 degrees. Spend. The stainless steel outer skin and trunk are beautiful in appearance, the whole body is beautiful in appearance, scientific in structure, light in weight and good in strength.
Fresh milk truck is also called milk tanker, liquid food truck, milk transfer truck, blue brand fresh milk truck, 6 ton fresh milk truck, 10 ton fresh milk truck, semi-trailer fresh milk truck
The tank structure of the fresh milk transporter is divided into three layers: the thermal insulation layer, the thermal insulation layer and the tank inner liner.
1. The inner tank of the fresh milk transport truck adopts food grade 304-2B stainless steel plate. All the welding seams of the tank are polished and ground to ensure that the liner is clean and free of sharp angles;
2. The middle layer of the tank body of the fresh milk truck adopts 8-10cm thick polyurethane foam insulation layer. Ensure that the temperature rise and fall ≤ 1°C in 24 hours when the temperature difference is 30 degrees during transportation, which greatly guarantees the original quality of the transported products;
3. The outer layer (protective layer of the thermal insulation layer) of the fresh milk transport vehicle tank is made of 2mm thick 304L stainless steel plate. The whole car body is beautiful in appearance, scientific in structure, light in weight and good in strength;
4. The fresh milk tank truck can set the tank into multiple bins according to user needs, and each single bin has a separate discharge port (artesian port) and feeding port (tank port);
5. The PIC automatic cleaning system is used in the fresh milk transport vehicle tank, and the cleaning device rotates 360 degrees in all directions to ensure that there is no dead angle for cleaning;
6. A vent valve is installed on the top of the tank of the fresh milk tank truck, which is automatically adjusted to reduce the evaporation loss of the liquid and prevent the deformation of the tank when positive and negative pressures are generated in the tank;
7. The amount of residual liquid in the fresh milk tank truck is small, which meets the requirement of less than 1% of the national standard;
8. The fresh milk tank truck can be equipped with optional refrigerator, flow meter, liquid level gauge, safety lock, anti-spill device, rock wool insulation, etc.
