| Vehicle general | Overall dimension | 5600*1850*2750 mm |
| Gross weight/Kerb weight | 2930/2800 kg | |
| Chassis Specification | ||
| Chassis | Chassis Brand | Foton |
| Cabin | Left hand drive or right hand drive | |
| Engine Model/Power | DAM15KL 85kw/115hp | |
| Emission standard | Euro VI | |
| Displacement | 1498 ml | |
| Gear box | 5 forwards 1 reverse | |
| Front and Rear axle | Front axle 1 tons rear axles 1.5 tons | |
| Wheelbase | 2850 mm | |
| Brake system | Oil Brake | |
| Tire | 185R14LT 8PR,165R14LT 8PR ,4 tyre with 1 spare tire | |
| Maximum speed | 100 km/h | |
| Led Van box body | ||
|
One side is a high-definition LED display screen, the other side is a roller advertising light box, the rear screen has a single red subtitle screen, and the front has a single red subtitle screen of 320 × 960 (mm); Equipped with 1 industrial computer, 2 waterproof sound columns, 1 power amplifier, 1 control console, and an external 220V mains power system. Adopting a composite steel frame body, top ventilated skylight, aluminum patterned floor, mechatronics control, circulating ventilation and cooling system, intelligent internal and external power distribution switching. Optional double-sided or three sided LED full-color display screen; Screen hydraulic lift 1.2 meters; Hand built stage boards (with the option of adding a manual stage); Replace the generator with a battery pack for power supply |
||
LED truck is also called LED video truck, led advertising truck, mobile led truck, led tv screen truck, led billboard truck, mobile advertisement vehicle, led display advertising truck, led mounted billboard truck advertisement truck, led screen truck, led display truck, etc.
Advertising vehicles generally consist of five parts. Including large screen system, power supply system, hydraulic system (some without parts), operating system, and chassis system. The chassis is generally selected as a light duty small chassis, and brands such as Foton, Dongfeng, Isuzu, Faw, JMC, JAC can be chosen. The power supply usually uses industrial 380V electricity or self generated generators.
Generator brand display
Gasoline engine led truck adopted Yihu brand gasoline generator power 6.5KW or 8KW
The advertising truck body material adopts a 5mm composite steel frame body, with high-temperature resistant aluminum patterned panels for the interior. The electronic control system is safe, intelligent, and automatically switches between the internal and external networks. The ventilation system is a powerful exhaust fan and sunroof. The floor material can be selected as wooden flooring or aluminum patterned panels. The industrial control system can be selected as wooden flooring or aluminum patterned panels. The industrial control system can be equipped with I4 high-end industrial control computer or USB direct insertion video playback system.
LED advertising vehicles have several advantages as new media promotion tools:
3 The promotional effect is good. From a distance, LED displays are more effective in attracting people's attention and achieving better promotional effects than ordinary plastic promotional paper.
